Carbon Steel
|
SIZE [OD]
|
ALL GRADES
|
| PRODUCTS |
MIN. |
MAX. |
|
| ELBOWS |
1/2" |
96" |
WPB,WPL6, WPHY52-65, WPC |
| BENDS |
1/2" |
36" |
WPB,WPL6, WPHY52-65, WPC |
| CAP |
1" |
96" |
WPB,WPL6, WPHY52-65, WPC |
| REDUCERS |
3/4" |
96" |
WPB,WPL6, WPHY52-65, WPC |
| TEES |
1/2" |
96" |
WPB,WPL6, WPHY52-65, WPC |
|
|
Stainless / Duplex / Super Duplex Stee
|
SIZE [OD]
|
ALL GRADES
|
| PRODUCTS |
MIN. |
MAX. |
|
| ELBOWS |
1/2" |
5" |
S304/L,S316/L, S31803,S32205,S32750,S32760 |
| BENDS |
1" |
14" |
S304/L,S316/L, S31803,S32205,S32750,S32760 |
| CAP |
3/4" |
16" |
S304/L,S316/L, S31803,S32205,S32750,S32760 |
| REDUCERS |
1/2" |
16" |
S304/L,S316/L, S31803,S32205,S32750,S32760 |
|
|
Forged Fittings – Carbon Steel
|
SIZE [OD]
|
ALL GRADES
|
| PRODUCTS |
MIN. |
MAX. |
|
| ELBOWS |
1/8" |
6" |
ASTM /ANSI A105, 350LF 2 |
| TEES |
1/8" |
6" |
ASTM /ANSI A105, 350LF 2 |
| COUPLINGS |
1/8" |
6" |
ASTM /ANSI A105, 350LF 2 |
| UNIONS |
1/8" |
6" |
ASTM /ANSI A105, 350LF 2 |
| CAPS |
1/8" |
6" |
ASTM /ANSI A105, 350LF 2 |
| PLUGS |
1/8" |
6" |
ASTM /ANSI A105, 350LF 2 |
| BUSHINGS |
3/8" |
6" |
ASTM /ANSI A105, 350LF 2 |
| INSERTS |
3/8" |
6" |
ASTM /ANSI A105, 350LF 2 |
|
|
Forged Fittings – Stainless Steel
|
SIZE [OD]
|
ALL GRADES
|
| PRODUCTS |
MIN. |
MAX. |
|
| ELBOWS |
1/8" |
6" |
ASTM 182/182M-F304/304L/ 316/316L |
| TEES |
1/8" |
6" |
ASTM 182/182M-F304/304L/ 316/316L |
| COUPLINGS |
1/8" |
6" |
ASTM 182/182M-F304/304L/ 316/316L |
| UNIONS |
1/8" |
6" |
ASTM 182/182M-F304/304L/ 316/316L |
| CAPS |
1/8" |
6" |
ASTM 182/182M-F304/304L/ 316/316L |
| PLUGS |
1/8" |
6" |
ASTM 182/182M-F304/304L/ 316/316L |
| BUSHINGS |
3/8" |
6" |
ASTM 182/182M-F304/304L/ 316/316L |
| INSERTS |
3/8" |
6" |
ASTM 182/182M-F304/304L/ 316/316L |
|
|
OUTLET
|
SIZE [OD]
|
ALL GRADES
|
| PRODUCTS |
MIN. |
MAX. |
|
| WELD-OUTLET |
1/2" |
36" |
ASTM /ANSI A105, 350LF 2/ASTM 182/182M-F304/304L/ 316/316L |
| SOCK-OUTLET |
1/2" |
4" |
ASTM /ANSI A105, 350LF 2/ASTM 182/182M-F304/304L/ 316/316L |
| THREAD-OUTLET |
1/2" |
4" |
ASTM /ANSI A105, 350LF 2/ASTM 182/182M-F304/304L/ 316/316L |
| NIP-OUTLET |
1/2" |
4" |
ASTM /ANSI A105, 350LF 2/ASTM 182/182M-F304/304L/ 316/316L |
| SWEEP-OUTLET |
1/2" |
4" |
ASTM /ANSI A105, 350LF 2/ASTM 182/182M-F304/304L/ 316/316L |
| ELB-OUTLET AND LAT-OUTLET |
1/2" |
24" |
ASTM /ANSI A105, 350LF 2/ASTM 182/182M-F304/304L/ 316/316L |
| LAT-OUTLET |
1/2" |
24" |
ASTM /ANSI A105, 350LF 2/ASTM 182/182M-F304/304L/ 316/316L |
| SWEEP-OUTLET |
1/2" |
24" |
ASTM /ANSI A105, 350LF 2/ASTM 182/182M-F304/304L/ 316/316L |
| NIPOFLANGES |
1/2" |
4" |
ASTM /ANSI A105, 350LF 2/ASTM 182/182M-F304/304L/ 316/316L |
|
|
PIPE NIPPLES
|
SIZE [OD]
|
ALL GRADES
|
| PRODUCTS |
MIN. |
MAX. |
|
| PIPE-NIPPLES 1/8” 10” |
1/8" |
10" |
ASTM /ANSI A105, 350LF 2/ASTM 182/182M-F304/304L/ 316/316L |
| SWAGE-NIPPLES 1/4”- 10” |
1/4" |
10" |
ASTM /ANSI A105, 350LF 2/ASTM 182/182M-F304/304L/ 316/316L |
|
|
NICKEL ALLOY STEEL
|
DESCRIPTION
|
| MANUFACTURING STANDARDS |
ASTM, EN, DIN |
| FITTING TYPES |
45°/90°/180° LR or SR Elbows, Concentric Reducers, Eccentric Reducers, Equal Tees, Reducing Tees, Caps |
| PROCESS |
Seamless and Welded |
| STEEL GRADES |
Alloy 825, Alloy 625, Alloy 600, Alloy 400, Alloy 201, Inconel C276, Alloy 200 |
| SIZES |
3/8” to 24”, – (10.2mm to 609.6mm)/td>
|
| SCHEDULES |
SCH STD – SCH160/XXS |
| THICKNESS |
1.5mm to 60.0mm |
| ENDS |
Bevelled/Plain |
